Single Acting Pneumatic Actuator is designed in threaded type design with the cam on the shaft. It comes with opening and closing direction to achieve a higher torque. In addition to this, it is designed in sturdy design for enhanced life and durability.
Single Acting Pneumatic Actuator
valve:
coil:
|
TEMPERATURE Range:
|
|
NBR
|
-20 C to +80 C
|
|
Viton
|
-20 C to +125 C
|
|
Flourosilicone
|
-60 C to +110 C
|
|
|
END STROKE (0?- 90?):
|
|
+5 Over travelling Possible for opening
|
-5 Under travelling Can be adjusted
|
|
|
WORKING PRESSURE:
|
Maximum working pressure 8 bar
|
|
AIR CONSUMPTION COMPARISON WITH OTHER REPUTED BRAND:
|
|
Model
|
Piston Inward Stroke ml / bar
|
Piston Outward Stroke ml / bar
|
|
(Uflow) AD50
|
128
|
137
|
|
Other Brand Y
|
260
|
110
|
|
Other Brand X
|
200
|
180
|
|
|
|
Features
Uflow has successfully developed Compact, Patented Aluminium Free Rack & Pinion Pneumatic Rotary Actuator, Consuming Low Volume of Air.
- Wear proof aluminium free Rack & Pinion design.
- Low air consumption with maximum torque due to compact design.
- Providing a hard-anodized body for high corrosion resistance.
- Smooth travelling stroke for extending the life of ball valve sheet.
- Finer teeth module for smoother operation, and jerk-free sliding.
- Maintenance-free design.
- Aluminium Extruded, Hard Anodized Body.
Torque Chart (SA)
|
Model No.
|
Spring Set
|
Spring Torque
|
3 bar
|
4 bar
|
5 bar
|
6 bar
|
Piston Outward Stroke, ml/bar
|
|
0 (Min)
|
90 (Max)
|
90 (Min)
|
0 (Max)
|
90 (Min)
|
0 (Max)
|
90 (Min)
|
0 (Max)
|
90 (Min)
|
0 (Max)
|
|
AS32
|
21
|
2
|
3
|
2
|
3
|
3
|
4
|
5
|
6
|
6
|
7
|
40
|
|
12
|
3
|
5
|
-
|
-
|
1
|
3
|
3
|
5
|
4
|
6
|
|
22
|
4
|
6
|
-
|
-
|
1
|
2
|
2
|
4
|
3
|
5
|
|
AS50
|
02
|
6
|
13
|
3
|
10
|
9
|
16
|
14
|
21
|
20
|
27
|
137
|
|
21
|
8
|
14
|
2
|
8
|
8
|
14
|
13
|
19
|
19
|
25
|
|
12
|
9
|
16
|
-
|
-
|
6
|
13
|
11
|
18
|
17
|
24
|
|
22
|
12
|
18
|
-
|
-
|
4
|
10
|
9
|
15
|
15
|
21
|
|
AS63
|
02
|
11
|
22
|
8
|
19
|
18
|
29
|
28
|
39
|
38
|
49
|
280
|
|
21
|
15
|
24
|
6
|
15
|
16
|
25
|
26
|
35
|
36
|
45
|
|
12
|
16
|
29
|
1
|
14
|
11
|
24
|
21
|
34
|
31
|
44
|
|
22
|
21
|
35
|
-
|
-
|
5
|
19
|
15
|
29
|
25
|
39
|
|
AS80
|
201
|
13
|
23
|
29
|
39
|
46
|
56
|
63
|
73
|
80
|
90
|
450
|
|
211
|
19
|
34
|
18
|
33
|
35
|
50
|
52
|
67
|
69
|
84
|
|
121
|
23
|
40
|
12
|
29
|
29
|
46
|
46
|
63
|
63
|
80
|
|
112
|
23
|
43
|
9
|
29
|
26
|
46
|
43
|
63
|
60
|
80
|
|
212
|
26
|
47
|
5
|
26
|
22
|
43
|
39
|
60
|
56
|
77
|
|
222
|
36
|
61
|
-
|
-
|
8
|
33
|
25
|
50
|
42
|
67
|
